Duty Cycle (intermittent per SAE J706 section 6.2): N/A ft (N/A m)
Mounting Bolt Torque: 32-34 ft*lbf (43 - 46 N*m)
Maximum Layers of Wire Rope: 2
Gear Reduction: 261
Brake Type: Automatic Cone
Contactor/Remote Type: Not Included
Standards Compliance: CE Machinery Directive 98/37/EC and 2006/42/EC CE Electromagnetic Compatibility 2004/108/EC ASME B30.5
ACCESSORIES
Control Pack-12V: PN 40709
Contactor Only-12V (Standard bracket): PN 34440
Contactor Only-12V (w/ bracket for cover): PN 34973
Contactor Cover (with remote plug): PN 36648
Contactor Cover (no plug): PN 35169
Remote Control Only: PN 88528
PERFORMANCE BY LAYER - 12V
Drum Layer
Line Load *
No Load Line Speed
Drum Capacity
lbf
kgf
kN
ft/min
m/min
ft
m
1
2000
907
8.9
14.7
4.5
20
6.1
2
1800
816
8.0
16.3
5.0
43
13.1
* Never exceed the Rated Capacity. Installation of a Rated Capacity Limiter is recommended.
FIRST LAYER PERFORMANCE - 12V
Line Load
Current Draw
Line Speed
Duty Cycle
lbf
kgf
Amps
ft/min
m/min
min/10min
0
0
13
14.7
4.5
Continuous
400
181
30
14.5
4.4
Continuous
800
363
48
13.9
4.2
6.7
1200
544
67
13.5
4.1
4.1
1600
726
87
13.0
4.0
2.9
2000
907
107
12.4
3.8
2.2
