WARN 85252 DC3000 LF Industrial Hoist, 24v, CW

by Warn
Original price $ 2,717.36 - Original price $ 2,717.36
Original price
$ 2,717.36
$ 2,717.36 - $ 2,717.36
Current price $ 2,717.36
Availability:
Only 2 left!

WARN 85252 DC3000 LF Industrial Hoist, 24v

The DC3000 hoist combines a powerful series wound DC motor with robust sealing and our proven 3-stage all metal geartrain. Permanent grease lubrication means years of trouble free service. All WARN hoists incorporate an automatic mechanical brake that holds full rated load. The durable powder coated finish stands up to the elements and looks great. The DC3000 hoist is built on WARN's robust large frame design with a cast aluminum drum to provide plenty of wire rope capacity. Controls and accessories available separately.

  • Powerful Series Wound DC Motor With Robust Sealing
  • Proven 3-Stage Planetary Gear Train
  • Clockwise rotation
  • Permanent Grease Lubrication
  • Automatic Disc Brake That Holds Full Rated Load
  • Large Frame With A Cast Aluminum Drum For Plenty Of Wire Rope Capacity
  • Limited 1 Year Warranty


TYPE Electric
RECOMMENDED USE Industrial
VOLTAGE 24 Volt
MOTOR TYPE Series Wound
THERMAL SHUTOFF No
DRIVE GEAR TYPE Planetary
GEAR REDUCTION RATIO 199:1
FREE SPOOLING No
BRAKE TYPE Automatic Disc
LINE DIAMETER (IN) No Rope
LINE LENGTH (FT) No Rope
LINE MATERIAL No Rope
FAIRLEAD TYPE No Fairlead
CONFORMS TO J706 STANDARDS No
REMOTE TYPE No Remote
MOUNTING HOLE QUANTITY 4
OPERATION TYPE Automatic
MOUNTING PATTERN LENGTH (IN) 8 Inch
MOUNTING PATTERN WIDTH (IN) 4-1/2 Inch
INCLUDES MOUNTING HARDWARE No
COLOR Black
MAX LINE PULL/ LINE SPEED 3000 Pound/ 14.9 Feet Per Minute
MAX AMP DRAW/ LINE PULL 120 Amp Draw/ 3000 Pound


Buy with confidence from Montana Jack's, we are your WARN Authorized Warranty and Service Center.
We are a Factory Direct WARN Distributor and we stand behind our WARN products for the full manufacturer's warranty period.

WRN-85252
